W-101-G
| Availability: | |
|---|---|
| Quantity: | |
| Model Number | W-101-101G | W-101-131G | W-101-132G | W-101-134G | W-101-151G | W-101-152G | W-101-181G |
| Feeding Type | Gravity | Gravity | Gravity | Gravity | Gravity | Gravity | Gravity |
| Nozzle Size(Φmm) | 1 | 1.3 | 1.3 | 1.3 | 1.5 | 1.5 | 1.8 |
| Air Pressure(Mpa) | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 |
| Air Consumption(L/min) | 75 | 145 | 225 | 250 | 145 | 225 | 170 |
| Spraying Distance(mm) | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Spraying Width(mm) | 130 | 170 | 175 | 220 | 180 | 190 | 190 |
| Fluid Output(ml/min) | 95 | 160 | 160 | 170 | 200 | 190 | 240 |
| Net Weight(g) | 368 | 368 | 368 | 368 | 368 | 368 | 368 |
| Suggested Air Compressor Power(Kw) | 0.4~0.75 | 0.4~0.75 | 0.75~1.5 | 0.75~1.5 | 0.75~1.5 | 1.5 | 1.5 |








| Model Number | W-101-101G | W-101-131G | W-101-132G | W-101-134G | W-101-151G | W-101-152G | W-101-181G |
| Feeding Type | Gravity | Gravity | Gravity | Gravity | Gravity | Gravity | Gravity |
| Nozzle Size(Φmm) | 1 | 1.3 | 1.3 | 1.3 | 1.5 | 1.5 | 1.8 |
| Air Pressure(Mpa) | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 |
| Air Consumption(L/min) | 75 | 145 | 225 | 250 | 145 | 225 | 170 |
| Spraying Distance(mm) | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Spraying Width(mm) | 130 | 170 | 175 | 220 | 180 | 190 | 190 |
| Fluid Output(ml/min) | 95 | 160 | 160 | 170 | 200 | 190 | 240 |
| Net Weight(g) | 368 | 368 | 368 | 368 | 368 | 368 | 368 |
| Suggested Air Compressor Power(Kw) | 0.4~0.75 | 0.4~0.75 | 0.75~1.5 | 0.75~1.5 | 0.75~1.5 | 1.5 | 1.5 |
